| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFS60 | Type: | Rear Axles |
|---|---|---|---|
| Brand: | Elite/OEM | Ratios: | Different Ratios |
| Load Capacity: | Higher Load Capacity | Output Torque: | Higher Output Torque |
| Design: | Customized Design | Ground Tooth: | Notchless Ground Tooth Root |
| Warranty: | 12months | Transport Package: | Wooden Boxes |
| Trademark: | Elite | Origin: | China |
| HS Code: | 8483402090 | Supply Ability: | 1000/Month |
| After-sales Service: | 24h | Condition: | New |
| Axle Number: | 1 | Application: | Engineering Equipment & Mining Equipment |
| Certification: | ISO | Material: | Iron |
| Customization: | Available | Customized Request |
Elite, committed to building a world-class drivetrain brand, strives to become a well-known manufacturer of planetary gearboxes, transfer cases and axles. With more than 20 years of experience in transmission design and manufacturing, Elite will provide you with customized gearboxes, transfer cases and axle solutions for any specific application.
Advantages
| 1 | It adopts POSI-STOP fully enclosed wet multi-disc braking, with spring braking and hydraulic release, ensuring a long service life for the brake | |
| 2 | Upon engine shutdown or parking, it automatically engages the brakes, ensuring safety and reliability | |
| 3 | The brake system includes a dedicated pressure oil cooling circuit, offering significant cooling effects and minimal wear on friction plates, suitable for frequent braking environments | |
| 4 | lt is also equipped with a NO-SPINanti-slip differential, which not only functions as a differential but also automatically transmits torque to the non-slipping wheels without manual intervention, enhancing productivity | |
| 5 | Our axle parts are completely interchangeable with the American Kessler Axle106 parts. | |
| Parameter | Unit | Value |
| Braking torque (new friction plate) | N.m | 40900-56200 |
| Braking torque (maximum wear of friction plates) | N.m | 35400-48700 |
| Brake spring compression force | N | 240000 |
| Brake-releasing pressure | Mpa | 10.1-18 |
| Maximum cooling pressure | Mpa | 0.07 |
| Speed ratio of main reducer | I | 2.12:1 |
| Speed ratio of wheel reducer | I | 12.43:1 |
| Total speed ratio | I | 26.35:1 |
| Maximum static load | N | 1200000 |
