| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFR | Type: | Rear Axles |
|---|---|---|---|
| Brand: | Elite/OEM | Ratios: | Different Ratios |
| Load Capacity: | Higher Load Capacity | Output Torque: | Higher Output Torque |
| Design: | Customized Design | Ground Tooth: | Notchless Ground Tooth Root |
| Warranty: | 12months | Transport Package: | Wooden Boxes |
| Trademark: | Elite | Origin: | China |
| HS Code: | 8483402090 | Supply Ability: | 1000/Month |
| After-sales Service: | 24h | Condition: | New |
| Axle Number: | 1 | Application: | Engineering Equipment & Mining Equipment |
| Certification: | ISO | Material: | Iron |
| Customization: | Available | Customized Request |
| 1 | It adopts POSI-STOP fully enclosed wet multi-disc braking, with spring braking and hydraulic release, ensuring a long service life for the brake | |
| 2 | Upon engine shutdown or parking, it automatically engages the brakes, ensuring safety and reliability | |
| 3 | The brake system includes a dedicated pressure oil cooling circuit, offering significant cooling effects and minimal wear on friction plates, suitable for frequent braking environments | |
| 4 | lt is also equipped with a NO-SPINanti-slip differential, which not only functions as a differential but also automatically transmits torque to the non-slipping wheels without manual intervention, enhancing productivity | |
| 5 | Our axle parts are completely interchangeable with the American Kessler Axle101 parts. | |
| Parameter | Unit | Value |
| Braking torque (new friction plate) | N.m | 26000-35800 |
| Braking torque (maximum wear of friction plates) | N.m | 22800-31400 |
| Brake spring compression force | N | 240000 |
| Brake-releasing pressure | Mpa | 11-18 |
| Maximum cooling pressure | Mpa | 0.07 |
| Speed ratio of main reducer | I | 2.12:1 |
| Speed ratio of wheel reducer | I | 12.43:1 |
| Total speed ratio | I | 26.35:1 |
| Maximum static load | N | 1200000 |
