| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFT017T | Load Capacity: | Higher Load Capacity |
|---|---|---|---|
| Delivery: | Fast Delivery | Ground Tooth: | Notchless Ground Tooth Root |
| Assembly: | Easy Assembly | Design: | Robust And Modular Design |
| Output Torque: | Higher Output Torque | Transport Package: | Wooden Boxes |
| Trademark: | Elite | Origin: | China |
| HS Code: | 8483402090 | Supply Ability: | 2200/Month |
| Application: | Motor, Motorcycle, Machinery, Agricultural Machinery | Function: | Change Drive Torque, Speed Changing, Speed Reduction |
| Hardness: | Hardened Tooth Surface | Step: | Three-Step |
| Type: | Planetary Gear Box | Warranty: | 18 Months |
| Customization: | Available | Customized Request |
| Model | HFT017T |
| Max. output torque: | 17000 N.m |
| Input speed | up to 4,000 rpm |
| Ratio: | 2-stage: 17, 20, 22, 27, 32, 38, 46, 50, 54 3-stage: 64, 77, 88, 103, 108, 112, 120, 135, 150 |
| Brake options | Hydraulically released parking brake on request |
| Dynamic Loading: | 160KN |
| Static Loading: | 332 KN |
| Applicable motors: | Cartridge axial piston hydraulic motors Flanged axial piston hydraulic motors Hydraulic orbit motors Electrical motors |
| Application: | Travel for Track, Chain and Wheel driving machines |
