| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFT180T3B091 | Design: | Robust And Modular Design |
|---|---|---|---|
| Ground Tooth: | Notchless Ground Tooth Root | Delivery: | Fast Delivery |
| Load Capacity: | Higher Load Capacity | Brakes: | Multiple Disc Brakes And Service Brakes |
| Ratio: | Different Ratios | Brand: | Elite/OEM |
| Custom: | Customized Design | Output Torque: | Higher Output Torque |
| Transport Package: | Wooden Boxes | Trademark: | Elite |
| Origin: | China | HS Code: | 8483402090 |
| Supply Ability: | 200/Month | Application: | Motor, Motorcycle, Machinery, Agricultural Machinery |
| Function: | Change Drive Torque, Speed Changing, Speed Reduction | Hardness: | Hardened Tooth Surface |
| Step: | Double-Step | Type: | Planetary Gear Box |
| Assembly: | Easy Assembly | Customization: | Available | Customized Request |
| Model | HFT180T |
| Max. output torque: | 109200 NM |
| Rated. output torque: | 43680NM |
| Input speed | up to 3,000 rpm |
| Ratio: | 91 |
| Static Brake Torque | ≥140000NM ;Spring brake, multi-disc service brakes |
| Dynamic Loading: | 1120KN |
| Static Loading: | 2170KN |
| Applicable motors: | Cartridge axial piston hydraulic motors Flanged axial piston hydraulic motors Hydraulic orbit motors Electrical motors |
| Application: | Travel for Track, Chain and Wheel driving machines ; for example bulldozer,Crawler excavator,Bracket Truck |
