| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFT020 | Step: | Three-Step |
|---|---|---|---|
| Type: | Planetary Gear Box | Output Torque: | Higher Output Torque |
| Custom: | Customized Design | Brand: | Elite/OEM |
| Ratio: | Different Ratios | Brakes: | Multiple Disc Brakes |
| Load Capacity: | Higher Load Capacity | Assembly: | Easy Assembly |
| Transport Package: | Wooden Boxes | Trademark: | Elite |
| Origin: | China | HS Code: | 8483402090 |
| Supply Ability: | 2200/Month | Package Size: | 80.00cm * 80.00cm * 100.00cm |
| Package Gross Weight: | 80.000kg | Application: | Motor, Motorcycle, Machinery, Agricultural Machinery |
| Function: | Change Drive Torque, Speed Changing, Speed Reduction | Hardness: | Hardened Tooth Surface |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| MODEL | MAX | RANGE OF RATIO | MAX.INPUT SPEED | ORBITAL HYD. | HYDRAULIC PISTON MOTOR | OIL QUANTITY | WEIGHT |
| OUTPUT | MOTOR | ||||||
| TORQUE | |||||||
| Nm | 1: | rpm | L | kg | |||
| HFT003 | 3000 | 6,8 | 4000 | √ | √ | 1-1.3 | 35-55 |
| HFT005 | 5000 | 5-55 | 4000 | √ | √ | 1-1.3 | 50 |
| HFT007 | 7000 | 11-57 | 4000 | √ | √ | 1.1 | 50 |
| HFT010 | 10000 | 25-63 | 4000 | √ | √ | 1.5 | 56-63 |
| HFT011 | 13000 | 26-59 | 4000 | √ | 2 | 80 | |
| HFT017 | 17000 | 26-141 | 4000 | √ | 2.5 | 90 | |
| HFT020 | 20000 | 27-51 | 4000 | √ | 2.5-3 | 105 | |
| HFT024 | 24000 | 44-170 | 4000 | √ | 2.5-3 | 105-120 | |
| HFT026 | 26000 | 26-62 | 4000 | √ | 3.5-4 | 140 | |
| HFT030 | 30000 | 23-42 | 4000 | √ | 5 | 120 | |
| HFT034 | 34000 | 51 | 4000 | √ | 5 | 140 | |
| HFT036 | 36000 | 12-173 | 4000 | √ | 5 | 140-170 |
| Model | HFT020T |
| Max. output torque: | 20000 N.m |
| Input speed | up to 4,000 rpm |
| Ratio: | 2-stage: 17, 20, 22, 27, 32, 38, 46, 50, 54 2-stage:78,88,90,102,120,140,153,170,227 |
| Brake options | Hydraulically released parking brake on request |
| Dynamic Loading: | 232KN |
| Static Loading: | 420 KN |
| Applicable motors: | Cartridge axial piston hydraulic motors Flanged axial piston hydraulic motors Hydraulic orbit motors Electrical motors |
| Application: | Travel for Track, Chain and Wheel driving machines |
