| Place of Origin: | China |
|---|---|
| Certification: | ISO 9001, ISO 14001, IATF16949 |
| Minimum Order Quantity: | 5 |
| Packaging Details: | Wooden Boxes |
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal |
| Supply Ability: | 90000 Pieces/Year |
| Model NO.: | HFT | Type: | Planetary Gear Reducer |
|---|---|---|---|
| Output Torque: | Higher Output Torque | Custom: | Customized Design |
| Brand: | Elite/OEM | Ratio: | Different Ratios |
| Brakes: | Multiple Disc Brakes | Load Capacity: | Higher Load Capacity |
| Delivery: | Fast Delivery | Ground Tooth: | Notchless Ground Tooth Root |
| Design: | Robust And Modular Design | Assembly: | Easy Assembly |
| Transport Package: | Wood Cases | Trademark: | Elite |
| Origin: | China | HS Code: | 8483402090 |
| Supply Ability: | 2200/Month | Application: | Motor, Electric Cars, Motorcycle, Machinery, Agricultural Machinery |
| Hardness: | Soft Tooth Surface | Installation: | 90 Degree |
| Layout: | Shunting | Gear Shape: | Conical - Cylindrical Gear |
| Step: | Three-Step | Customization: | Available | Customized Request |
| MODEL | MAX OUTPUT TORQUE | RANGE OF RATIO | MAX. INPUT SPEED | ORBITAL HYD. MOTOR | HYDRAULIC PISTON MOTOR | INTERCHANGEABLE MODEL |
| Nm | 1: | rpm | ||||
| HFT003L | 3000 | 5-21 | 4000 | √ | √ | OMNI SL02 Auburn Gear Model 40 |
| HFT005L | 5000 | 5-75 | 4000 | √ | √ | OMNI SD06/SL06 Auburn Gear Model 6B Auburn Gear Model 7 |
| HFT010L | 10000 | 35-79 | 4000 | √ | √ | OMNI SL12 Auburn Gear Model 8b |
| HFT017L | 17000 | 18-171 | 4000 | √ | Rexroth GFB17 Auburn Gear Model 9 | |
| HFT024L | 24000 | 38-222 | 4000 | √ | Rexroth GFB24 Auburn Gear Model 10B | |
| HFT026L | 26000 | 18-63 | 4000 | √ | Rexroth GFB26 | |
| HFT036L | 36000 | 24-270 | 4000 | √ | Rexroth GFB36 | |
| HFT040L | 40000 | 20-66 | 4000 | √ | Rexroth GFB40 | |
| HFT045L | 46000 | 66-205 | 4000 | √ | Siebenhaar | |
| HFT050L | 50000 | 28-1817 | 4000 | √ | Rexroth GFB50 | |
| HFT060L | 60000 | 26-510 | 3500 | √ | Rexroth GFB60 | |
| HFT080L | 80000 | 40-190 | 3500 | √ | Rexroth GFB80 | |
| HFT110L | 11000 | 29-219 | 3500 | √ | Rexroth GFB110 |
Elite HFTE planetary drives incorporate an integrated, maintenance-free electric motor and offer significant benefits, including compact dimensions, low noise and high efficiency. HFTE Series drives are designed for use with all kinds of aerial platforms and other types of mobile machinery, for indoor and outdoor use. This advanced powertrain solution uses a two- or three-stage gearbox offering reduction ratios of up to 1:153 to satisfy the widest possible range of needs. The gearbox is coupled with a low-voltage induction motor (BT Series), specially developed for traction power and control applications.
