| Model NO.: | HFT | Layout: | Shunting |
|---|---|---|---|
| Gear Shape: | Bevel Gear | Step: | Four-Step |
| Type: | Planetary Gear Reducer | Output Torque: | Higher Output Torque |
| Custom: | Customized Design | Brand: | Elite/OEM |
| Ratio: | Different Ratios | Brakes: | Multiple Disc Brakes |
| Load Capacity: | Higher Load Capacity | Delivery: | Fast Delivery |
| Ground Tooth: | Notchless Ground Tooth Root | Design: | Robust And Modular Design |
| Assembly: | Easy Assembly | Transport Package: | Wooden Boxes |
| Trademark: | Elite | Origin: | China |
| HS Code: | 8483402090 | Supply Ability: | 2200/Month |
| Package Size: | 80.00cm * 80.00cm * 100.00cm | Package Gross Weight: | 150.000kg |
| Application: | Motor, Electric Cars, Machinery, Agricultural Machinery | Hardness: | Hardened Tooth Surface |
| Installation: | Vertical Type | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Elite GFT Travel Drives are unsurpassed by any crawler or milling machines. Thanks to compact, rugged design, high torque and load capabilities, and optional mechanical lifetime seals, these solutions are the best possible option for the machine. All units are available with a fail-safe parking brake and most have the option of cartridge type fixed or variable systems.
Features:
Compact structure and space-saving design
Robust main bearing system
High torque capacity
High load capacity
Integrated static multiple disk parking brake
Optional Disconnect device for towing
Optional Quick disconnection device
Simple mounting
Easy oil change
Low-noise running operation
Specifications:
| Model | HFT007T2B |
| Max. output torque: | 7000 N.m |
| Rated output torque: | 3500 N.m |
| Input speed | up to 4,000 rpm |
| Ratio: | 18, 25, 32, 38, 48, 55,57 |
| Brake options | Hydraulically released parking brake on request |
| Dynamic Loading: | 132KN |
| Static Loading: | 277 KN |
In conclusion, ELITE Hydraulic offers quality, value, and professional power transmission solutions that cater to a wide variety of industries. With their expertise, experience, and commitment to customer satisfaction, you can be sure that you're in safe hands when working with them. Whether you need travel gearbox, electrical drive, travel drive,slew gearbox,winche gearbox,cutter gearbox,truck mixer gearbox,twin shaft mixer or other hydraulic transmission solutions, you can trust ELITE Hydraulic to provide you with the best possible solutions. Contact them today to learn more about their power transmission products and services.
